Central to its activities, CETh has developed a range of low voltage local heat treatment machines capable of meeting our customers most demanding expectations. (welding pre/post-heating, stress relief and treatment, using electrical resistances).

Our engineers are heat treatment experts and work with the machines they develop. This field experience allows us to offer reliable machines, benefiting from constant improvements and meeting the highest requirements in terms of heat treatment. We are particularly proud of our automated regulation, controlled by a user-friendly touch interface offering high flexibility and precision.

IHM
IHM

Machine specifications

 TT12TT13cc
(Under development)
TT30TT60TT90TT120TT180TT130
Power
12 kW13kW30kW60kW90kW120kW
(2 x 60kW)
180kW
(2 x 90kW)
130kW
Primary suply
400V tri
20A
400V tri
50A
400V tri
50A
400V tri
90A
400V tri
140A
400V tri
180A
400V tri
270A
400V tri
190A
Secondary outputs
46V46V46V46V (1)46V (1)46V (1)46V (1)46V (2)
Control panel & regulatorr
The regulation system is managed by a programmable logic controller (PLC) via an HMI on all our machines.
Controlled heating zones
2 ou 663 ou 66 ou 1266 ou 126 ou 128
+ 2 sécurités
Recorder (3)
NumériqueExterne optionnelNumérique NumériqueNumérique NumériqueNumériqueNumérique
Dimensions
270 x 670 x 580270 x 670 x 680700 x 700 x 1700800 x 1100 x 1200950 x 1100 x 12001750 x 900 x 12501750 x 900 x 1250800 x 900 x 2000
Weight
95kg43kg300kg390kg500kg900kg1000kg650kg

All the machines are Certifié CEcertified.

(1) Customizable in 80V
(2) Supports y2 single loop digital controler.
(3) Supports intgrated or external strio chart recorder.

Options

Enregistreur video Yokogawa

Equiped with Yokogawa or Eurotherm video recorders, our machines can also be equiped on demand, with strip chart recorders.

CETh TT machines can also be equipped with RJ-45 Lan port, allowing for remote maintenance, message services and machine networking.

Télémaintenance
Port RJ 45
Support cable alim

 Optional hooks for power cable. Get fixed to lifting rings.

System diagram

Schema montage UK

Our resistances

Our standard range of TT machines, supplies very modular electrical resistances due to their flexibility, solid and minimizing the risk of contact between the filament and the treated part.These resistances heaters enable the positioning of certain thermocouples, avoiding the appearance of cold zones due to, for instance, the spacing of ceramic pads. They also have the capacity to work in conduction as well as by radiation.

composition resistance
